Product

SERVO DRIVE

Product ID: NPG3700

FOC(Field Oriental Control)

Permanent Magnet Brushless Servo Motor with with CPU build-in which is adapted efficiency calculation from position to amperage 14 thousand times per second to assign the appropriate rpm or Nm. In addition, energy saving of PMSMs is almost twice than squirrel cage induction motors with the adder of pulley consumers.



  • High Efficiency of Rated Amperage
  • Ultra High Effect of Start Amperage
  • Start with High Torque
  • w/o Encoder
  • WIFI Monitoring(OPTIONAL)
  • App Modification at Any time Online Monitoring(OPTIONAL)




WIFI APP DOWNLOAD Download Now !
Features:
  • FOC(Field Oriental Control)

Permanent Magnet Brushless Servo Motor with with CPU build-in which is adapted efficiency calculation from position to amperage 14 thousand times per second to assign the appropriate rpm or Nm. In addition, energy saving of PMSMs is almost twice than squirrel cage induction motors with the adder of pulley consumers.



  • High Efficiency of Rated Amperage

Permanent Magnet Brushless Servo Motor with high efficiency performance especially shows on rated amperage with long ED % application. This is due to the motor temperature increase slowly and consumed energy very little than squirrel cage induction motors. High Efficiency of Rated Amperage



  • Ultra High Effect of Start Amperage

Ultra-high starting current efficiency compared with the traditional squirrel-cage induction motors which are up to ten times of the rated amperage at the starting. Servo motors need to be increased only ten percent more of the starting amperage, make the servo motors are more suitable for use in frequent start working conditions



  • Start with High Torque

Permanent Magnet Brushless Servo Motors start with full torque of output compared with squirrel cage induction motors and more suitable for high torque of working condition.





  • w/o Encoder

Servo Drive is designed without encoder and adapted Field Oriental Control for PMSM system design, the patent design, which high technical operations save the costs of encoder installation, adjustment, and maintenance.

  • WIFI Monitoring(OPTIONAL)

The built-in WiFi wireless module is optional and can be used in servo motors instantly uploaded to sever, providing remote monitoring to users for use under operating conditions. The error can be eliminated using online customers, recorded, and records can be traced back more customers to use. If there is any abnormal condition, systems can be improved or notify customers the relevant parts replacement service life early maturing.



  • App Modification at Any time Online Monitoring(OPTIONAL)

Customized mobile-apps can be 24 hours of Internet access to monitor and eliminate the use of remote client.

See more complete detail

1.Technical Data

1.1 AC220V

XFOC- DRIVER SERIAL-220

600

750

1500

2200

3700

5500

7500

11000

15000

18500

22000

XHR-   MOTOR SERIAL-220

600

750

1500

2200

3700

5500

7500

11000

15000

18500

22000

Horse Power(HP)

3/4

1

2

3

5

7.5

10

15

20

25

30

Max applicable motor output (KW)*1

0.6

0.75

1.5

2.2

3.7

5.5

7.5

11

15

18.5

22

Rated Output

Drive Capacity (KVA)

1.0

1.3

2.8

4

6.6

9.5

13

19

26

33

40

Rated Output Current(A)

2.2

2.8

5.5

8.1

13.6

20.2

27.6

40.4

55.1

68.0

80.9

Max Short Time Current(A)

4.4

5.5

12.6

18

29.7

36

49.5

86.4

118.8

151.2

150

OC-Tripping Current(A)

11.03

13.79

15.1

21.5

35.6

43.1

59.3

103.6

142.6

181.4

180

Stall Current (A)

4.412

5.515

12.6

18

29.7

36

49.5

86.4

118.8

151.2

150

Max Output voltage (V)

3-Phase 200V~240V relative to input voltage

Max Output Frequency、rpm

Synchronous Motor max to12000RPM;

Overload Curve

Curve A

Power

Rated Input Voltage & Frequency

3-Phase 200V-240V、50/60Hz

Rated Input Current(A)

2.5

3.1

6.1

9.0

15.1

22.5

30.6

44.9

61.3

75.6

89.9

Allowable Voltage Fluctuation

         '+10∽-15%

Allowable Frequency Fluctuation

         ±5%

Order Information:
  • Minimum Order: Negotiable
  • OEM/ODM Product, Branded Product, Buyer's Label Offered
